Relax Hybrid
Technological research based on the latest innovations developed in the field of heating and cooling, the study of furnishing trends to seek an exclusive and contemporary design, were the design lines of this revolutionary product. RELAX HYBRID, inserted in a system powered by a heat pump and also set up for air conditioning, gives its best by integrating the cooling function with the heating function. RELAX HYBRID is available in vertical and horizontal versions in four models with different heating and cooling powers. It is offered in six colors combined with a Medium Gray frame perfect for creating tone on tone but also harmony or contrast with the color of the radiant plate. It can be equipped with a LED lighting system that enhances its elegant profile and creates a suggestive mood in the environment.
The images on this page have the sole purpose of depicting the product. Finishes and models may not have a perfect match with the actual product.
Calculate the power
How to choose the Relax Hybrid radiator for your home? How to know what is the right power to heat each room? Online thermal requirement allows you to identify the most suitable radiator for your living space
Calculate the thermal power of your Relax Hybrid
Configure your relax
Loading...
Configure your relax
-
Thermal power
Construction features
- ventilated radiator with painted steel structure, complete with insulation
- available in widths 920, 1120, 1320 mm
- configurable with left or right hydraulic connection
- touch display on the radiator, located on the opposite side to the chosen hydraulic connection position, insulation class I
- removable filter
- customisable in six colours
- LED lighting system (optional)
| Model | Depth (mm) | Height (mm) | Width (mm) | Weight (kg) | Capacity (lt) |
|
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| RELAX HYBRID CON LED | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| 650 x 1120 con LED | 107,0 | 650 | 1120 | 35,20 | 2,89 | 2.701,0 2.130,0 1.568,0 1.018,0 | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| 650 x 1320 con LED | 107,0 | 650 | 1320 | 40,00 | 3,35 | 3.529,0 2.770,0 2.027,0 1.305,0 | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| 650 x 920 con LED | 107,0 | 650 | 920 | 29,00 | 2,43 | 2.394,0 1.897,0 1.405,0 921,0 | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| 1800 x 630 con LED | 107,0 | 1800 | 630 | 62,40 | 6,09 | 2.758,0 2.188,0 1.623,0 1.065,0 | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| RELAX HYBRID SENZA LED | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| 650 x 1120 | 107,0 | 650 | 1120 | 35,20 | 2,89 | 2.701,0 2.130,0 1.568,0 1.018,0 | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| 650 x 1320 | 107,0 | 650 | 1320 | 40,00 | 3,35 | 3.529,0 2.770,0 2.027,0 1.305,0 | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| 650 x 920 | 107,0 | 650 | 920 | 29,00 | 2,43 | 2.394,0 1.897,0 1.405,0 921,0 | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| 1800 x 630 | 107,0 | 1800 | 630 | 62,40 | 6,09 | 2.758,0 2.188,0 1.623,0 1.065,0 | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
* Heating performance certified according to EN16430-2:2015 UNI EN16430-2:2015 ** Sound power measurement according to UNI EN ISO 3744:2010
Standard equipment
- installation template
- wall-mounting system with screws and dowels
- assembly, use and maintenance instructions
| Type | Description | Document | Downloads |
|---|---|---|---|
|
Technical document |
|||
|
Catalogs |
Catalog 2023 | Catalog 2023 | |
|
Catalogs |
Color chart | Color chart | |
|
Manual |
FOISTR1350M | FOISTR1350M |
