Xilo Electric
XILO Electric is an electric steel bathroom towel radiator. Available in 3 heights and in 2 width.
Loading...
Salvataggio in corso...
Discover accessories
Loading...
Construction features
- electric steel towel warmer radiator
- horizontal elements featuring rectangular tubes 50x10 mm section
- side round manifolds with a 30 mm diameter
- complete with thermal liquid
- red textile power cable, lenght 1200 mm, SCHUKO plug
- electronic control with integrated WiFi card
- WiFi electronic control in the same color as the radiator
- class II, IP24
| Model | Depth (mm) | Height (mm) | Width (mm) | Weight (kg) | Electric Power (Watt) |
|---|---|---|---|---|---|
| 1156 16 rails 3 espaces | 38,0 | 1156 | 506 | 15,02 | 500 |
| 1520 21 rails 4 espaces | 38,0 | 1520 | 506 | 19,62 | 750 |
| 1520 21 rails 4 espaces | 38,0 | 1520 | 606 | 22,35 | 1000 |
| 1744 25 rails 4 espaces | 38,0 | 1744 | 606 | 26,35 | 1200 |
Standard equipment
- 4 adjustable wall fixing brackets in the same color of the radiator
- the model with WiFi electronic control, type E, includes the electronics in the same finish as the radiator
| Type | Description | Document | Downloads |
|---|---|---|---|
|
Catalogs |
Catalog 2023 | Catalog 2023 | |
|
Catalogs |
Color chart 2023 | Color chart 2023 | |
|
Installation Manual |
987M1220_Rad_ELETTRICI_EH_IRSAP_FUNZ | 987M1220_Rad_ELETTRICI_EH_IRSAP_FUNZ | |
|
Installation Manual |
1028M0219_FUNZION_ELETTRICO_EK | 1028M0219_FUNZION_ELETTRICO_EK | |
|
Installation Manual |
1015M1218_tabella_ECODESIGN_2018_TIPOLOGIA_D | 1015M1218_tabella_ECODESIGN_2018_TIPOLOGIA_D | |
|
Installation Manual |
1013M0521_tabella_ECODESIGN_2021_TIPOLOGIA_H_(imb. IR) | 1013M0521_tabella_ECODESIGN_2021_TIPOLOGIA_H_(imb. IR) | |
|
Installation Manual |
1276M1120_IRA06720_XILO_EE_EV | 1276M1120_IRA06720_XILO_EE_EV | |
|
Installation Manual |
1263M0221_tabella_ECODESIGN_TIPOLOGIA_E | 1263M0221_tabella_ECODESIGN_TIPOLOGIA_E | |
|
Installation Manual |
1298M0721_Quick_start_guide_Rad_elettrici | 1298M0721_Quick_start_guide_Rad_elettrici | |
|
Installation Manual |
1305M0321_RAD_ELETTR_LUXURY_EE_EV_funz | 1305M0321_RAD_ELETTR_LUXURY_EE_EV_funz |
Calculate the power
How to choose the Xilo Electric radiator for your home? How to know what is the right power to heat each room? Online heat demand allows you to identify the most suitable radiator for your living space
